MINIPAK 600 Rugged Mobile Case – Internet On the Go

Digital Navigator MINI PAK 600 with Cradlepoint IBR600 Mobile Internet Case

Cradlepoint IBR600c in a portable all-in-one hard case, including cellular and wi-fi antennas and offers several valuable benefits, especially in situations where reliable and mobile connectivity is essential. Great for traveling salesmen who need a secure connection.

The Cradlepoint IBR600 is a 4G LTE high performance, semi-ruggedized router designed for mobile and IoT applications.

IBR600

By leveraging the robustness and advanced features of the Cradlepoint IBR600c within a protective case, you gain a more versatile, reliable, and powerful portable networking solution compared to a standard MiFi device. Using a Cradlepoint IBR600c over a MiFi device offers several advantages, especially in more demanding or specialized applications. Known for its ruggedness and compact size, the Cradlepoint IBR600c can be highly useful for various portable applications when placed inside our protective case.

Here are some key benefits:

Performance and Reliability:

Enhanced Durability and Protection:
Placing the Cradlepoint IBR600c in a protective case ensures it is shielded from physical damage, such as drops, impacts, dust, and moisture, making it more reliable in various environments.

Higher Performance and Reliability:
The Cradlepoint IBR600c typically provides better performance in terms of network connectivity, signal strength, and data throughput compared to standard MiFi devices. It is designed for more demanding applications and can handle higher data loads more efficiently.

Advanced Features and Functionality:

Multiple Ethernet Ports:
The IBR600c has multiple Ethernet ports, allowing for wired connections to multiple devices, which is not typically available on MiFi devices.

Advanced Network Management:
Cradlepoint devices offer more advanced network management features, such as traffic prioritization, VPN support, and advanced security features, providing better control over your network.

Dual-SIM Capability:
The IBR600c often supports dual SIM cards, allowing for automatic failover between different carriers to ensure constant connectivity.

External Antenna Support:
The ability to connect external antennas can significantly improve signal reception and coverage, which is not usually possible with MiFi devices.

Power Options:
The Cradlepoint IBR600c can be powered through various means, including AC power, vehicle power adapters, and even battery packs. This flexibility ensures it can stay operational in various situations and locations.

Scalability and Integration:
The IBR600c can be integrated into larger network setups and managed remotely through Cradlepoint’s NetCloud service. This makes it suitable for businesses and remote deployments where scalability and centralized management are essential.

Ruggedized Design:
Although the IBR600c is already designed to be more rugged than typical consumer MiFi devices, placing it in a protective case further enhances its ability to withstand harsh conditions, making it ideal for use in field operations, construction sites, or outdoor events.

Hardware Specs

Category – IoT
Cloud Management – Yes
Wireless Connectivity – LTE
5G Status – No
Form Factor – Metal
Ethernet Ports – 1 GbE, 1 FE (LAN/WAN switchable)
USB Ports – 1
Serial Ports 0
Network Operator Standards – PTCRB (U.S.), GCF (global)
Network Operator Certifications – AT&T, Verizon
Public Safety Networks – FirstNet Trusted, Verizon Frontline: *See data sheet for model applicability
Throughput- 75 Mbps (Firewall)
VPN Tunnel Count – 5
Wi-Fi – 802.11 b/g/n (Wi-Fi 4)
GNSS/GPS – Passive
PoE – No
Operating Temperature – -20 °C to 60 °C (-4 °F to 140 °F)
Private Cellular Network – Yes — 4G LTE (No CBRS)
Public Safety Networks – ESN, FirstNet Trusted, Verizon Frontline (See data sheet for model applicability)
Throughput – 940 Mbps (Firewall)
VPN Tunnel Count – 10
Wi-Fi – Dual-band, dual-concurrent; 802.11ac Wave 2 (Wi-Fi 5)
GNSS/GPS – Active
PoE – No
Operating Temperature – -30 °C to 70 °C (-22 °F to 158 °F)
Rack Mountable – No
Private Cellular Network – Yes — 4G LTE (No CBRS)

Case Specs

Protective, Waterproof & Shockproof
Outer: 13.37″ x 11.62″ x 6″ Inner: 11.81″ x 8.87″ x 5.18″
Waterproof protection for up to 1 meter fully submerged with a rubber gasket lining.
Lockable Fittings TSA Approved.
Stackable Design
Pressure equalization valve
12V 3A Power Supply Adapter
Waterproof GPS Active Antenna 28dB Gain, 3-5VDC
120mm Silent Green LED Case Fan
125 Volt 15 Amp Flanged Inlet, Power Inlet Socket with Waterproof Cap
4 x RJ45 Cable Connectors, with Shielding Cable Coupler-CAT5E
2 x Panorama 600-6000MHz Desk Mount 2×2 MiMo 4G/5G Antenna
3 x Dual Band Bluetooth-Wi-Fi 2.4GHz 5GHz 5.8GHz 6dBi MIMO RP-SMA Male Antenna
VELCRO Brand Heavy Duty Fasteners retain components for service and maintenance ease.
ACCEPTS OTHER CELLULAR MODEM PRODUCTS LIKE DIGI, SIERRA WIRELESS, PEPWAVE, etc.

Cellular vs. Starlink

Ease of Use with Existing Technology:
Cradlepoint utilizes well-established cellular networks, which means the technology is mature and widely supported. No apps are needed. One button activation is all there is. SSID and password is on the case’s handle tag.

Instant Service:
Unlike Starlink, which may have wait times for equipment and activation, cellular service can be activated quickly as long as there some coverage. Our cases arrive with the sims installed and activated. They work right out of the box. This is a significant advantage for users who need internet asap.

Plan Flexibility:
All of our Verizon data plans are month to month and can be changed at any time. Customers can also opt to use their own carrier and data plans if they wish.

Network Reliability:
Relying on established cellular towers can offer more consistent service in certain areas compared to the relatively new and expanding satellite network of Starlink, which might experience initial teething problems like signal intermittency in extreme weather or due to satellite repositioning.

Low Latency:
Compared to most ISP providers, our system has significantly lower latency, with an average latency between 20-30 ms as previously indicated.

Real World Applications

Using a Cradlepoint IBR600c in a protective hard case opens up a variety of portable use cases, especially in demanding environments where reliability and performance are critical.

Here are some examples:

Field Operations:

Emergency Response:
Provide robust and reliable internet connectivity for first responders, enabling real-time communication, data transfer, and access to emergency management systems.

Remote Work Sites:
Supply internet access to remote construction sites, enabling project management, communication, and data sharing among team members.

Disaster Recovery:
Offer a portable internet solution for disaster recovery teams, ensuring continuous connectivity in areas where infrastructure has been damaged.

Event Management:

Outdoor Events:
Provide Wi-Fi coverage for outdoor events like festivals, fairs, and sports events, ensuring vendors, staff, and attendees have access to reliable internet.

Mobile Offices:
Set up temporary mobile offices with full network capabilities at events, trade shows, or temporary business locations.

Public Safety and Law Enforcement:

Mobile Command Centers:
Equip mobile command centers with reliable internet connectivity for law enforcement, fire departments, and other public safety agencies.

Surveillance and Monitoring:
Deploy portable surveillance units with internet connectivity for live video streaming and remote monitoring.

Healthcare:

Mobile Clinics:
Enable internet access for mobile healthcare units, allowing for electronic medical record access, telemedicine, and communication with remote healthcare providers.

Remote Patient Monitoring:
Support remote patient monitoring and telehealth services in rural or underserved areas.

Transportation and Logistics:

Fleet Management:
Provide internet connectivity for fleet vehicles, enabling real-time tracking, communication, and data transfer between vehicles and central offices.

Passenger Wi-Fi:
Offer reliable Wi-Fi services for passengers in buses, trains, or other modes of transport.

Broadcasting and Media:

Live Streaming:
Provide high-speed internet for live streaming from remote locations, ensuring high-quality video transmission for news, sports, or other live events.

Field Reporting:
Enable field reporters to quickly upload stories, videos, and photos from the field to their newsrooms.

Education:

Mobile Classrooms:
Supply internet connectivity for mobile classrooms, enabling online learning and access to educational resources in remote or underserved areas.

Field Trips:
Provide internet access during educational field trips, allowing for interactive learning and real-time research.

Agriculture:

Smart Farming:
Enable internet connectivity for agricultural equipment and IoT devices in the field, supporting precision farming, real-time monitoring, and data collection.

Remote Monitoring:
Facilitate remote monitoring and control of irrigation systems, weather stations, and other critical farm infrastructure.

Adventure and Outdoor Activities:

Expeditions:
Provide reliable internet access for scientific expeditions, research teams, and adventure groups in remote locations, ensuring communication and data sharing.

Campsites:
Offer internet connectivity for campsites and RV parks, enhancing the experience for campers and travelers.

Why MINIPAK 600 Mobile Internet

Ease of Deployment: With everything neatly packed in a portable hard case, the setup process becomes incredibly straightforward. One button operation lets Users quickly deploy the Cradlepoint IBR600 and its antennas in various locations without the need for complex installations.

Mobile Connectivity: The portability of the all-in-one hard case with antennas allows for on-the-go connectivity. It’s perfect for businesses or individuals who require internet access while traveling, working in the field, or participating in events.

Rugged Protection: The hard case provides robust protection for the Cradlepoint IBR600 and its antennas against physical damage, impacts, and environmental elements. This is especially beneficial in outdoor, remote, or harsh working conditions.

Enhanced Signal Reception: The included antennas are optimized for the Cradlepoint IBR600, providing improved signal reception and extended network coverage. This ensures a more reliable and stable connection, even in areas with weaker signals.

Secure Connectivity: The Cradlepoint IBR600 supports various security protocols, and the hard case can include additional security measures, such as locking mechanisms, to protect the device from unauthorized access.

Robust Cloud Managed IoT Solution

For organizations requiring robust connectivity for IoT networks — with installed routers numbering from hundreds to many thousands — Cradlepoint’s NetCloud Service for IoT with the IBR600C router provides a comprehensive cloud managed network solution. When coupled with advanced IoT features, it provides troubleshooting and diagnostics with in-band and out-of-band management, extensive analytics and insights, and extensibility and integrations such as Microsoft Azure IoT Central. Cradlepoint’s NetCloud-managed IoT endpoints can be rapidly deployed and easily scaled to accommodate the diverse requirements of organizations.

Redundancy and Failover: The portable setup with multiple antennas allows for load balancing and failover capabilities. If one connection experiences issues, the router can automatically switch to another available connection, ensuring continuous internet access.

Temporary Networks: The all-in-one hard case with antennas is ideal for creating temporary networks in emergency situations, construction sites, or remote locations. It enables rapid deployment of a reliable network hub without the need for permanent infrastructure.

Disaster Recovery: In disaster scenarios, having a pre-configured portable setup with antennas allows first responders and emergency teams to quickly establish a secure communication network for coordination and data sharing.

Field Research and IoT Deployments: Researchers, field workers, or IoT (Internet of Things) devices can benefit from the mobility and connectivity offered by the portable MINIPAK’s Cradlepoint IBR600 setup with antennas.

Remote Monitoring and Surveillance: The portable setup is excellent for remote monitoring and surveillance applications, providing real-time data transmission and video streaming capabilities.

The Cradlepoint IBR600C Series Router for IoT networks is a semi-ruggedized, cloud-managed LTE router, built for IoT and M2M applications. They provide a resilient, LTE connection ideal for use in high-availability, portable, or fixed uses. The IBR600C Series is available with IoT NetCloud Service Plans, which provide features optimized for each unique deployment.

When coupled with the NetCloud IoT service plan, the IBR600C router provides a compact semi-ruggedized 4G LTE router solution for connecting and protecting IoT devices at scale. It is ideal for use in high-availability portable or fixed applications such as surveillance cameras, digital signs, oil and gas monitoring, and parallel networking. With an extensive list of features, it can be confidently deployed in the field, in buildings, or in embedded systems to deliver complete visibility, security, and control of connected devices anywhere.
